MRocky-150/45A Fully Automatic Twin Rockwell Hardness Tester
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（1 scaled
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（2）
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（3）
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（4）
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（5）
MRocky 150 45A Fully Automatic Twin Rockwell Hardness Tester 图（6）
Video Demonstration
Product Features & Applications
Product Feature：
- Closed loop system, ready for use upon power-on
- Adopts a novel head-down pressing structure with a fixed stage,eliminating coaxiality errors common in traditional screw types
- Fully automatic operation: loading, dwell time, and unloading oftest forces
- High-precision guide rails control precise head movement
- High-definition LCD touch screen, clear display, simple andconvenient operation
- High-precision displacement sensor, hardness resolution up to1 HR
- Wide range of test scales: Rockwell, Plastic Rockwell, SuperficialRockwell
- Equipped with an external Bluetooth printer
- Hardness values for all scales can be calibrated
- USB and RS232 interfaces for computer connection
Product Application：
- Mechanical Manufacturing
Used to detect the hardness of various mechanical components to ensure product quality and performance
- Aerospace
Can accurately measure material hardness, providing important data support for aerospace design and manufacturing
- Metal Smelting and Processing
Used for hardness testing of raw materials and finished products to evaluate their quality and performance
Technical Specifications
| Name | Fully Automatic Rockwell Hardness Tester | |
| Model | MRocky-150/45A | |
| Control System | Precision Stepper Control System | |
| Dwell Time | 1~60s | |
| Initial Test Force | 10kgf（98.07N） | 3kgf（29.4N） |
| Total Test Force | 60、100、150kgf （588.4、980.7、1471N） | 15、30、45kgf （147.1、294.2、441.3N） |
| Indenter Specifications | Diamond Rockwell indenter; Φ1.5875mm steel ball indenter | |
| Test Height | 280mm | |
| Test Throatl | 170mm | |
| Measurement Scales | HRA、HRB、 HRC、HRD、HRE、 HRF、HRG、HRH、HRK、 HRL、 HRM、HRP、HRR、 HRS、HRV、HR15N、 HR30N、HR45N、 HR15T、HR30T、 HR45T、HR15X、HR30X、 HR45X、HR15Y、 HR30Y、HR45Y、 HR15W、 HR30W、HR45W | |
|
Conversion Scales |
HRA、HRB、HRC、HRD、HRE、HRF、HRG、HRH、HRK、HS、HV、HK、HBW、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T |
|
| Hardness Resolution | 0.1HR | |
| Data Output | Bluetooth; RS232 interface; USB interface | |
| Power Supply | AC220V，50Hz | |
| Dimensions (LxWxH) | 400*855*620mm | |
| Net Weight | Approx.180KG | |
Standard Configuration
| Name | Quity |
| qHardness Tester Mainframe | 1set |
| Diamond Rockwell Indenter | 1piece |
| Φ1.5875mm Carbide Ball | 1piece |
| Indenter | 1piece |
| Φ1.588mm Carbide Ball | 1piece |
| Φ100mm Flat Test Anvil | 1piece |
| 90*110mm V-shape Test Anvil | 1piece |
| Hardness Block (HRA) | 1piece |
| Hardness Block (HRB) | 1piece |
| Hardness Block（HRC） | 3pieces |
| Hardness Block（HR15N） | 1piece |
| Hardness Block（HR30N） | 2 pieces |
| Hardness Block（HR30T） | 1piece |
| Bluetooth Printer | 1piece |
| Spirit Leve | 1piece |
| Leveling Screws | 4pieces |
| 65mm65mm Screwdriver | 1piece |
| Power Cord | 1piece |
| Fuse 2A | 2pieces |
| Anti-dust Cover | 1piece |
| User Manual (incl. Certificate, Packing List) | 1copy |
Optional Configuration
| Tungsten Carbide Balls |
| Various Worktables |
| Various Hardness Blocks |
| Internal Machine Parts |
| Various Indenters |
