Auto Press 2-30/50/120/400 Dual Mold Cylinder Automatic Mounting Press
Scan QR
Auto Press 2 30 50 120 400（1）
Auto Press 2 30 50 120 400（2）
Auto Press 2 30 50 120 400（3）
Auto Press 2 30 50 120 400（4）
Auto Press 2 30 50 120 400（5）
Auto Press 2 30 50 120 400（6） scaled
Product Features & Applications
Product Feature：
One-touch operation; the whole mounting force including heating, heat preservation, automatic pressure compensation, cooling and unloading is completed automatically.
High specimen preparation efficiency. Adopting advanced heating technology and optimized cooling system; it takes approximately 7 minutes to mount specimens of Φ30 mm
(1.18 inches), and about 25 minutes for Model 2-30.
Dual-Cylinder design with independent operation for each Cylinder.
Pneumatic pressurization for Model 2-30 & 2-50, hydraulic pressurization for Model 2-120 &2-400; maximum pressure reaches 400 kgf (Model 2-400).
Standard specimen size: Φ30 mm (1.18″); optional sizes: Φ40 mm (1.57 inches) and Φ50mm (1.97 inches); custom sizes are available.
Max. heating temperature: 180C for pneumatic models, 200℃ for hydraulic models.
Equipped with pulse cooling technology for adjustable cooling intensity and water conservation.
Three optional cooling modes: temperature control, time control and manual control.
Multiple safety protections; power cuts off automatically in case of overheating.
The housing is made of high-strength high-temperature resistant composite material, featuring rust resistance and corrosion resistance.
7-inch color touch screen for user-friendly operation.
Real-time display of temperature curve.
Supports up to 20 sets of mounting recipe settings.
No need to remove the top cover for quick opening of the mold cavity.
Comes with hot mounting release agent as standard for easy demoulding after mounting.
External circulating water tank is available as an accessory.
Compliant with standards: GB/T 13298, ASTM E3-11, ISO 20580.
Product Application：
Uniform mounting of miniature samples to ensure flat surface and intact edges.
Analysis of hardness gradient, carbide distribution, heat treatment quality and failure analysis.
Inspection of quenched layer, tempered microstructure, fatigue cracks, coating layer and metallographic consistency of materials.
Rating of metallographic structure, grain size measurement, inclusion analysis, depth detection of carburized layer/nitrided layer.
Technical Specifications
| Item | Dual Mold Cylinder Automatic Mounting Press | |||
| Model | Auto Press 2-30 | Auto Press 2-50 | Auto Press 2-120 | Auto Press 2-400 |
| Working Mode | Automatic | |||
| Pressurization Mode | Pneumatic | Hydraulic | ||
| Cooling Mode | Water Cooling | |||
| Specification Size | Standard: 1.18inches(φ30 mm); Optional: φ1.57inches (40 mm), 1.97inches(φ50 mm) | |||
| Maximum Pressure | 30MPa | 50 MPa | 120 MPa | 400 MPa |
| Maximum Temperature | 180℃ | 200℃ | ||
| Power | 1.2kw | 2.4kw | 2.4kw | 3kw |
| Air Supply | Required | / | ||
| Air Water Filter | Standard Accessory | Not equipped | ||
| Cooling Water | Required | |||
| Power Supply | 220V 50Hz | |||
| Overall Dimensions | 23.62 x 22.05 x3 inches(600*560*430mm) | |||
| Weight | 45kg（99.21lb） | 45kg（99.21lb） | 65kg（143.30lb） | 77kg（169.76lb） |
Standard Configuration
| Item | Quantity | Photo |
| Mainframe | 1 | |
| Graduated Cylinder | 1 | |
| Funnel | 1 | |
| Spoon | 1 | |
| General Hot Mounting Compound | 1 | |
| Hot Mounting Release Agent | 1 | |
| Operation Manual | 1 | |
| Certificate of Conformity | 1 | |
| Warranty Card | 1 |
Optional Configuration
| Edge Retaining Hot Mounting Compound |
| Transparent Hot Mounting Compound |
| Conductive Hot Mounting Compound |
| Section Clamp |
