Measuring Machine Composite Fixture
88afe48938a4365c1879031307a1321e
621f87a30daf9a560ca4e99c168f8de2
Cb57db53fc9a7d96ec361024548b431e
D0e643f526f2d951c8645b797ab79faf
D9015c787160983446803a8fa48752a0
Technical Specifications
| Name |
Qty |
Code |
     |
| Elastic Pressing Plate |
4 |
MS-100-S100 | |
| Short Steel Wire Pressing Plate |
4 |
MS-100-S101 | |
| Long Steel Wire Pressing Plate |
4 |
MS-100-S102 | |
| Short Pressing Plate Support Rod |
8 |
MS-100-S103 | |
| Long Pressing Plate Support Rod |
3 |
MS-100-S104 | |
| Support Rod with Diameter 6*5mm |
3 |
MS-100-S0605 |
|
| Support Rod with Diameter 6*10mm |
6 |
MS-100-S0610 |
|
| Support Rod with Diameter 6*25mm |
6 |
MS-100-S0625 |
|
| Support Rod with Diameter 9*5mm |
3 |
MS-100-S0905 |
|
| Support Rod with Diameter 9*10mm |
6 |
MS-100-S0910 |
|
| Support Rod with Diameter 9*20mm |
6 |
MS-100-S0920 |
|
| Support Rod with Diameter 9*25mm |
6 |
MS-100-S0925 |
|
| 2Support Rod with Diameter 12×10mm |
6 |
MS-100-S1210 |
|
| Support Rod with Diameter 12×25mm |
6 |
MS-100-S1225 |
|
| Support Rod with Diameter 6×10mm (Flat Head) |
4 |
MS-100-S0610F |
|
| Support Rod with Diameter 9×10mm (Flat Head) |
4 |
MS-100-S0910F |
|
| Support Rod with Diameter 12×10mm (Flat Head) |
4 |
MS-100-S1210F |
|
| Adjustable Height Support Rod with Diameter 9mm |
2 |
MS-100-S1009 |
|
| Spherical Support Rod with Diameter 6mm |
2 |
MS-100-S106 | |
| Male Connector of Commutation Square |
2 |
MS-100-F100 | |
| Elastic Bracket Locking Screw |
2 |
MS-100-F101 | |
| Right Angle Positioning Block |
1 |
MS-100-F102 | |
| Sliding Connection Plate |
4 |
MS-100-F103 | |
| Commutation Square |
1 |
MS-100-F104 | |
| Commutation Square Base |
1 |
MS-100-F105 | |
| Elastic Bracket |
1 |
MS-100-F106 | |
| M4-M8 Conversion Rod |
4 |
MS-100-F107 | |
| Transparent Sliding Connection Plate |
8 |
MS-100-F108 | |
| M3 Wrench |
1 |
MS-100-F109 | |
| Firmware Tray |
1 |
MS-100-F110 | |
| M4×10 Screw |
20 |
MS-100-F111 | |
| Packing Box |
1 |
MS-100-P100 |
