Coating Thickness Gauge Probe

F1

F1/90°

F10
Probe Model F1 F1/90° F10
Code CTP01250F00 CTP01250F90 CTP10000F10
Operating Principle Magnetic
Substrate Material Magnetic Metal (Steel, Iron Etc.)
Coating Material Non-magnetic Coating(Aluminum, Chromium, Copper, Enamel, Rubber, Paint Etc.)
Measuring Range (μm) 0~1250 0~10000
Low Range Resolution (μm) 0.1 10
Accuracy One-Point Calibration (μm) ±(3%H+1) ±(3%H+10)
Two-Point Calibration (μm) ±((1~3)%H+1) ±((1~3)%H+10)
Measuring Conditions Min Curvature Radius (mm) 1.5 Flatten 10
Diameter of The Min Area (mm) Φ7 Φ7 Φ40
Critical Thickness of Substrate (mm)   0.5   0.5   2
FN
Probe Model FN
Code CTP01250FN0
Measuring Range (μm) 0~1250
Low Range Resolution (μm) 0.1
Accuracy One-Point Calibration (μm) ±(3%H+1)
Two-Point Calibration (μm) ±((1~3)%H+1)
N1
Probe Model N1
Code CTP01250N00
Operating Principle Eddy Current
Substrate Material Non-magnetic Metal Substrate(Copper, Aluminum, Zinc, Tin Etc.)
Coating Material Non-conductive Coating (Enamel, Rubber, Paint, Plastic And Etc.)
Measuring Range (μm) 0~1250
Low Range Resolution (μm) 0.1
Accuracy One-Point Calibration (μm) ±(3%H+1.5)
Two-Point Calibration (μm) ±((1~3)%H+1.5)
Measuring Conditions Min Curvature Radius (mm) 3
Diameter of The Min Area (mm) Φ5
Critical Thickness of Substrate(mm) 0.3
